Core Positioning
Ultra-High Purity Inert Atmosphere (O₂/H₂O ≤1ppm) | For Laboratory R&D & Precision Material Synthesis
Core Specifications
| Specification | Parameter |
|---|---|
| H₂O/O₂ Control Precision | ≤1ppm |
| Chamber Leakage Rate | ≤0.05vol%/h |
| Chamber Material/Thickness | Stainless Steel 1.4301 (SUS304), 3 mm |
| Chamber Dimension/Volume | 1200(L)×750(W)×900(H)mm / 0.8 m³ |
| Front Window Configuration | 8 mm safety tempered glass / 10 mm polycarbonate (optional) |
| Vacuum Pump Specification | EDWARDS RV12 Rotary Vane Pump, Flow Rate 12 m³/h, Vacuum Degree <2×10⁻³ mbar (absolute) |
| Gas Purification System | GP20 Single Purification Column (GP200 Dual Column optional), Fully Automatic Regeneration |
| Circulation Air Volume | 0-100 m³/h Oil-Free High-Speed Fan |
| Working Air Pressure | ±12 mbar Automatic Pressure Control |
| Working Gas | N₂/Ar/He (Purity ≥99.999%) |
| Certifications | ISO9001, CE, UL Certified |
| Warranty | 1-Year Full Machine Warranty, Lifetime Maintenance, 365 Worry-Free Extended Warranty |
Core Performance Advantages
- Ultra-Trace H₂O/O₂ Precision Control (≤1ppm)：Delivers stable inert atmosphere via GP20 purification system, paired with ZrO₂ oxygen sensor and corrosion-resistant water analyzer to prevent sample oxidation & moisture damage—ideal for lithium battery and organometallic research with ultra-high cleanliness requirements.
- Ultra-Low Leakage Airtight Design：3 mm thickened 304 stainless steel chamber with electromagnetic high-vacuum valves & integrated valve structure optimizes pipelines, reducing leak points significantly. Helium mass spectrometry leak detection ensures airtightness and cuts inert gas consumption.
- Imported European Core Components：SIEMENS PLC touch screen & EDWARDS RV12 vacuum pump enable 24/7 uninterrupted stable operation. All key parts are sourced from world-leading manufacturers with cutting-edge European technology.
- Automated Intelligent Operation：One-click control via SIEMENS touch screen, with automatic data recording, self-diagnosis and power-off auto-restart. Foot-operated pressure control replaces manual operation, and the automatic gas replacement & cleaning system reduces experimental operation difficulty drastically.
- Humanized Structural Design：870/950 mm height-adjustable stand with movable casters, large transfer chamber with sliding tray (φ360mm×600mm optional) featuring a lightweight easy-open door, and 0.4/0.8 mm butyl rubber gloves (optional) for superior operational ease.
- High-Quality Configuration Assurance：All stainless steel gas flow pipelines, HEPA (High-Efficiency Particulate Air) Filter (filtration <0.3μm), top-mounted LED anti-reflective lighting, and dual inlet & outlet filtration ensure the purity of the experimental environment in every detail.
Precise Scenario Adaptation
- Advanced Material R&D：Synthesis & characterization of lithium-ion battery cathode/anode materials, semiconductor materials, and nanomaterials
- Chemical Research：Anhydrous & oxygen-free organic synthesis, preparation & storage of sensitive compounds, organometallic experiments
- Precision Testing：Ultra-high cleanliness detection & packaging of electronic components and optical materials
- General Laboratory R&D：Processing, experimental operation & storage of various H₂O/O₂ sensitive samples
Solving Core Research Pain Points
Eliminates sample failure and experimental data deviation from excessive H₂O/O₂, ensuring precise, repeatable research outcomes.
Integrated valve structure + ultra-low leakage design reduces gas consumption and equipment failures, cutting lab operational & maintenance costs.
24/7 continuous stable operation adapts to long-term uninterrupted experiments, improving research efficiency and shortening R&D cycles.
The water analyzer supports 3 free cleanings for repeated use, avoiding scrapping after a single contamination and saving consumable investment significantly.
Modular solenoid valve design enables easy replacement and simplified leak detection, lowering the difficulty of subsequent equipment maintenance.
Customizable Configurations | Tailored to Your Research Requirements
- Chamber Specifications：Optional lengths of 1200/1500/1800/2400 mm, customizable integrated/split/double-side operation structures
- Functional Modules：Precise selection of automatic cleaning system, organic solvent adsorption system, and H₂O/O₂ analyzer
- Transfer Chamber Types：Optional φ360/390 mm large transfer chamber, φ150 mm small transfer chamber, and square transfer chamber
- Additional Equipment：-35℃ low-temperature refrigerator (18L/32L), 200℃ temperature-controlled heating chamber, openable front window
- Accessory Options：Hard aluminum alloy/polyoxymethylene glove ports, 0.4/0.8 mm butyl rubber gloves, dry pump as a replacement for rotary vane pump
Professional Supporting Services
🔧 Global Localized Service：Local service centers in Beijing, Shanghai, Guangzhou, Wuhan, Chengdu, Xi’an, Changchun and other cities, providing global on-site installation, commissioning and one-on-one guidance from multilingual engineers. Professional logistics & customs clearance assistance is available for international shipments.
📦 Warranty & Extended Warranty：1-year full machine warranty with exclusive protection for core components and lifetime maintenance; optional 365 Worry-Free Extended Warranty to enjoy free warranty (excluding consumables) after the original warranty expires.
🔌 Genuine Consumables Supply：Long-term stable supply of special consumables such as butyl rubber gloves, gaskets and sensors with preferential prices.
📞 24/7 Technical Support：400-086-8156 unified customer service hotline with 24-hour online Q&A; modular accessories are in stock for fast fault handling.
📋 One-Stop Service：Establish exclusive user files and provide one-stop full-process services including equipment maintenance, upkeep and operation training.
Call to Action
👉 Get a Free Custom Quote & Solution
👉 One-on-One Technical Consultation | Engineer-Matched Optimal Configurations
👉 Learn More About 365 Worry-Free Extended Warranty
